Description
This A3 Workbook is designed for Engineering Graphics and Design educators and learners for Grade 10.
This EGD Workbook is aligned with the Subject Assessment Guidelines (SAGS) as provided by the Independent Examination Board (IEB).
This Grade 10 workbook consists of 12 Modules covering all the required learning material. Each lesson is unique and consists of a question and space to complete the drawing. This workbook aims to help develop the user’s basic and advanced drawing skills through employing freehand and instrument drawings, and include the following to cater for the unique requirements of the IEB:
- Multiple choice analytical questions
- 6-Part mechanical assemblies
- Sectional isometric drawings introduced in this Gr.10 workbook
- Civil: SANS compliant symbols, IEB aligned wording of questions and scale 1:50 sectional elevations
Many new worksheets, exercises and improvements have been added to our 2nd edition for 2027!
